Brioso
Overview
The Brioso provides high speed inspection of a continuous web of pouches and packets filled with dry powders and products. Pouches and packets can be made from paper, plastic, metalized film or aluminum foil.
The Brioso leverages Peco InspX’s renowned X-ray inspection architecture to provide the highest level of speed and contaminant detection capability. The compact inspection assembly inspects as the pouches travel vertically and installs in a short linear space with minimum disruption to line operations. The Brioso’s advanced software minimizes false rejects and makes it quick and easy to change the inspection setup for different types of products.
Features
Streamlined Installation
Industrial design allows for tool-less line installation over your conveyor, providing contactless inspection in a compact footprint
Modular Design
All subsystems have been designed with the maximum system availability, redundancy, and fault tolerance in mind
Real-Time Remote Support
Integrated wireless connectivity allows for secure remote support 24/7 globally. Peco InspX can resolve over 95% of customer issues with our powerful remote diagnostics software
Robust IT Security
Fully integrated end-to-end IT security offerings ensure your networks aren’t vulnerable and are defended from any outside threats. Optional IoT module allows for seamless SCADA integration
High Performance Generator
Features a high powered X-ray generator designed for continuous duty-cycle operation and no maintenance
High Speed Inspection
The Brioso is designed for very high speed environments of up to 600 linear feet per minute, which depending on packet size translates to speeds in excess of 5,000 packets per minute
Typical Applications
Continous Packet Web / Bandolier
Pouches
High Speed Operations
Manufacturers can easily operate at speeds over 1000 containers per minute - Peco InspX offers inspection, checkweighing and fill monitoring capable to match such performance.
Service
Peco InspX strives to deliver the very best service in the industry and the quality of our service is well recognized across our global customer base.
Software
Our inspection and detection software is custom designed constantly enhanced for technical excellence at our R&D facility in Silicon Valley.
Made in America
All systems are manufactured in our newly expanded facility in Modesto, California.
Tech Specs
Technical Information
Architecture
Top down X-ray system
Conveyor
Integrates natively with Cloud, RA Jones, Fuji, and other filler systems
X-ray Tube Configuration
High reliability integrated X-ray generator
Aperture Size
Max Width: 8 in
Max Height: 4 in
Environment
Standard: IP 66/NEMA 4X
Optional: IP 69K, Passivation
Line Speed
Up to 650 ft/min (198 m/min)
Input Voltage
Available in 120 or 240 VAC options
Air Supply
80 psi @ 5 cfm (for ejection only)
Ambient Temperature
33°F – 113°F (1°C – 45°C)
Air Conditioning
Optional
Diode Size
Configurable to 0.8 mm or 0.4 mm
Container Ejection
Integrates with downstream printer and cutter for automatic package rejection
Dimensions (LxDxH)
37 x 36 x 72 in (940 x 915 x 1,813 mm)
Safety Rating
Redundant – Category 4, Performance Level E
Computer
Solid State Industrial PC with Windows 10 and integrated AV
Connectivity
Integrated WiFi, Ethernet or Cellular Connection
Supported SCADA Systems
Ignition, Wonderware, FactoryTalk, Kepware and other OPC-UA compliant systems
Supported Cloud Platforms
Azure IoT Hub, AWS and Google Cloud via MQTT
Operator Interface
17" touchscreen
Construction
Standard: 304 Stainless Steel
Optional: 316L/Passivated
Technical Information
