Largo
Overview
The Largo is designed to handle the largest packages and cases at speeds up to 200 feet (67 meters) per minute.
The Largo features a unique design that utilizes twin X-ray beams for inspection, which allows it to uniformly inspect even the largest of packages.
A wide array of ejection options allows for easy handling of rejected packages.
Features
Modular Design
All subsystems have been designed with the maximum system availability, redundancy, and fault tolerance in mind
Conveyor Drive
Remotely controlled Powerflex 525-based variable frequency drive and sealed sanitary rollers
Real-Time Remote Support
Integrated wireless connectivity allows for secure remote support 24/7 globally. Peco InspX can resolve over 95% of customer issues with our powerful remote diagnostics software
Robust IT Security
Fully integrated end-to-end IT security offerings ensure your networks aren’t vulnerable and are defended from any outside threats. Optional IoT module allows for seamless SCADA integration
No Requirement for Container Spacing
This inspection geometry does not require any container spacing between adjacent containers
High Performance Generator
Features a high powered X-ray generator designed for continuous duty-cycle operation and no maintenance
Typical Applications
Large Cases
Large Bags of Product
Bulk Packaged Dry Ingredients
High Speed Operations
Manufacturers can easily operate at speeds over 1000 containers per minute - Peco InspX offers inspection, checkweighing and fill monitoring capable to match such performance.
Service
Peco InspX strives to deliver the very best service in the industry and the quality of our service is well recognized across our global customer base.
Software
Our inspection and detection software is custom designed constantly enhanced for technical excellence at our R&D facility in Silicon Valley.
Made in America
All systems are manufactured in our newly expanded facility in Modesto, California.
Tech Specs
Technical Information
Architecture
Top down X-ray system
Conveyor
Integrated conveyor with built-in drive and controls
X-ray Tube Configuration
High reliability integrated X-ray generator
Aperture Size
Max Width: 36 in (914 mm)
Max Height: 17 in (432 mm)
Environment
Standard: IP 66/NEMA 4X
Optional: IP 69K, Passivation
Line Speed
Up to 436 ft/min (133 m/min)
Input Voltage
Available in 120 or 240 VAC options
Air Supply
80 psi @ 5 cfm (for ejection only)
Ambient Temperature
33°F – 113°F (1°C – 45°C)
Air Conditioning
Standard
Diode Size
Configurable to 0.8 mm, 0.4 mm and 0.2 mm
Container Ejection
Full range of high-speed ejection and diversion options available
Dimensions (LxDxH)
65 x 67 x 96 in (1,650 x 1,700 x 2,439 mm)
Safety Rating
Redundant – Category 4, Performance Level E
Computer
Solid State Industrial PC with Windows 10 and integrated AV
Connectivity
Integrated WiFi, Ethernet or Cellular Connection
Supported SCADA Systems
Ignition, Wonderware, FactoryTalk, Kepware and other OPC-UA compliant systems
Supported Cloud Platforms
Azure IoT Hub, AWS and Google Cloud via MQTT
Operator Interface
17" touchscreen
Construction
Standard: 304 Stainless Steel
Optional: 316L/Passivated
Technical Information
